Brand:
Manufacturer's Part Number:
K12-210-2
Part Type:
Summit Racing Part Number:
CCA-K12-210-2
UPC:
036584460237
Cam Style:
Hydraulic flat tappet
Basic Operating RPM Range:
1,500-5,500
Camshaft Use:
Street/Strip
Intake Duration at 050 inch Lift:
218
Exhaust Duration at 050 inch Lift:
218
Duration at 050 inch Lift:
218 int./218 exh.
Advertised Intake Duration:
268
Advertised Exhaust Duration:
268
Advertised Duration:
268 int./268 exh.
Intake Valve Lift with Factory Rocker Arm Ratio:
0.454 in.
Exhaust Valve Lift with Factory Rocker Arm Ratio:
0.454 in.
Valve Lift with Factory Rocker Arm Ratio:
0.454 int./0.454 exh.
Lobe Separation (degrees):
110
Grind Number:
CS 268H-10
Computer-Controlled Compatible:
No
Lifters Included:
Yes
Lifter Style:
Hydraulic flat tappet
Valve Springs Included:
Yes
Outside Diameter of Outer Spring (in.):
1.254 in.
Retainers Included:
Yes
Locks Included:
Yes
Valve Stem Seals Included:
Yes
Timing Chain and Gears Included:
Yes
Timing Chain Style:
Link belt
Assembly Lubricant Included:
Yes
Pushrods Included:
No
Rocker Arms Included:
No
Gaskets Included:
No
Valve Springs Required:
No
Quantity:
Sold as a kit.
CARB EO Number:
Emissions:
California EO Approved
